Windows XP
Windows XP was originally released in year 2001. It included improved graphics, and a more user-friendly environment. Windows XP was built on the core of Windows 2000 but adds greater stability for most desktop users plus a fancier graphical user interface. Although the goal of perfect security continues to elude the OS, Service Pack 2 (SP2) improves matters over the original release and rolls up enhancements added between release and mid-2004.
Operating System Design
The Windows XP kernel is considered a modified-microkernel, and is also sometimes called a macro kernel. Although most system components run in the same address space, some subsystems run as user-mode server processes and many of the design objectives are the same as Mach.
A hardware abstraction layer (HAL) is an abstraction layer, implemented in software, between the physical hardware of a computer and the software that runs on that computer. Its function is to hide differences in hardware from most of the operating system kernel, so that most of the kernel-mode code does not need to be changed to run on systems with different hardware. On a PC, HAL can basically be considered to be the driver for the motherboard and allows instructions from higher level computer languages to communicate with lower level components, such as directly with hardware.
A microkernel is the near-minimum amount of software that can provide the mechanisms needed to implement an operating system (OS). These mechanisms include low-level address space management, thread management, and inter-process communication (IPC). If the hardware provides multiple rings or CPU modes, the microkernel is the only software executing at the most privileged level (generally referred to as supervisor or kernel mode) Traditional operating system functions, such as device drivers, protocol stacks and file systems, are removed from the microkernel to run in user space
The monolithic approach is to defines a high-level virtual interface over the hardware, with a set of primitives or system calls to implement operating system services such as process management, concurrency, and memory management in several modules that run in supervisor mode. Even if every module servicing these operations is separate from the whole, the code integration is very tight and difficult to do correctly, and, since all the modules run in the same address space, a bug in one module can bring down the whole system
Device Drivers
Device drivers frequently perform direct memory access (DMA), and therefore can write to arbitrary locations of physical memory, including over kernel data structures. Such drivers must therefore be trusted. It is a common misconception that this means that they must be part of the kernel. In fact, a driver is not inherently more or less trustworthy by being part of the kernel.
While running a device driver in user space does not necessarily reduce the damage a misbehaving driver can cause, in practice it is beneficial for system stability in the presence of buggy (rather than malicious) drivers: memory-access violations by the driver code itself (as opposed to the device) may still be caught by the memory-management hardware. Furthermore, many devices are not DMA-capable, their drivers can be made untrusted by running them in user space
Executive
The Windows Executive services make up the low-level kernel-mode portion. It deals with I/O, object management, security and process management. These are divided into several subsystems, among which are Cache Manager, Configuration Manager, I/O Manager, Local Procedure Call (LPC), Memory Manager, Object Manager, Process Structureand Security Reference Monitor (SRM). Grouped together, the components can be called Executive services (internal name Ex). System Services (internal name Nt), i.e., system calls, are implemented at this level, too, except very few that call directly into the kernel layer for better performance. Diagram : Windows XP system architecture
Object Manager
The Object Manager (internal name Ob) is an executive subsystem that all other executive subsystems, especially system calls, must pass through to gain access to Windows NT resources—essentially making it a resource management infrastructure service. The object manager is used to reduce the duplication of object resource management functionality in other executive subsystems, which could potentially lead to bugs and make development of Windows NT harder. To the object manager, each resource is an object, whether that resource is a physical resource (such as a file system or peripheral) or a logical resource (such as a file). Each object has a structure or object type that the object manager must know about.
Cache Controller
Closely coordinates with the Memory Manager, I/O Manager and I/O drivers to provide a common cache for regular file I/O. Uniquely, the Windows Cache Manager operates on file blocks (rather than device blocks), for consistent operation between local and remote files, and ensures a certain degree of coherency with memory-mapped views of files, since cache blocks are a special case of memory-mapped views and cache misses a special case of page faults.
Configuration Manager
Implements the Windows registry.
I/O Manager
Allows devices to communicate with user-mode subsystems. It translates user-mode read and write commands into read or write IRPs which it passes to device drivers. It accepts file system I/O requests and translates them into device specific calls, and can incorporate low-level device drivers that directly manipulate hardware to either read input or write output. It also includes a cache manager to improve disk performance by caching read requests and write to the disk in the background.
Local Procedure Call (LPC)
Provides inter-process communication ports with connection semantics. LPC ports are used by user-mode subsystems to communicate with their clients, by Executive subsystems to communicate with user-mode subsystems, and as the basis for the local transport for MSRPC.
Memory Manager
Manages virtual memory, controlling memory protection and the paging of memory in and out of physical memory to secondary storage, and implements a general-purpose allocator of physical memory. It also implements a parser of PE executables that lets an executable be mapped or unmapped in a single, atomic step.
Starting from Windows NT Server 4.0, Terminal Server Edition, the memory manager implements a so-called session space, a range of kernel-mode memory that is subject to context switching just like user-mode memory. This lets multiple instances of the kernel-mode Win32 subsystem and GDI drivers run side-by-side, despite shortcomings in their initial design. Each session space is shared by several processes, collectively referred to as a "session".
PnP Manager
Handles Plug and Play and supports device detection and installation at boot time. It also has the responsibility to stop and start devices on demand—this can happen when a bus (such as USB orFireWire) gains a new device and needs to have a device driver loaded to support it. Its bulk is actually implemented in user mode, in the Plug and Play Service, which handles the often complex tasks of installing the appropriate drivers, notifying services and applications of the arrival of new devices, and displaying GUI to the user.
Power Manager
Deals with power events (power-off, stand-by, hibernate, etc.) and notifies affected drivers with special IRPs (Power IRPs).
Security Reference Monitor (SRM)
The primary authority for enforcing the security rules of the security integral subsystem. It determines whether an object or resource can be accessed, via the use of access control lists (ACLs), which are themselves made up of access control entries (ACEs). ACEs contain a security identifier (SID) and a list of operations that the ACE gives a select group of trustees—a user account, group account, or login session--permission (allow, deny, or audit) to that resource.
Environment Subsystem
The environment subsystem was designed to run applications written for many different types of operating systems. None of the environment subsystems can directly access hardware, and must request access to memory resources through the Virtual Memory Manager that runs in kernel mode. Also, applications run at a lower priority than kernel mode processes.
There are three main environment subsystems: the Win32 subsystem, an OS/2 subsystem and a POSIX subsystem.
The Win32 environment subsystem can run 32-bit Windows applications. It contains the console as well as text window support, shutdown and hard-error handling for all other environment subsystems. It also supports Virtual DOS Machines (VDMs), which allow MS-DOS and 16-bit Windows (Win16) applications to run on Windows NT.
The ANSI/POSIX Environment (APE) is a compatibility subsystem that implements an interface close to ANSI C and POSIX, with some common extensions. It also includes a POSIX-compatible shell.
DLL (Dynamic-link library)
DLLs provide a mechanism for shared code and data, allowing a developer of shared code/data to upgrade functionality without requiring applications to be re-linked or re-compiled. From the application development point of view Windows and OS/2 can be thought of as a collection of DLLs that are upgraded, allowing applications for one version of the OS to work in a later one, provided that the OS vendor has ensured that the interfaces and functionality are compatible.
DLLs execute in the memory space of the calling process and with the same access permissions which means there is little overhead in their use but also that there is no protection for the calling EXE if the DLL has any sort of bug.
